YOM September 2019
Total Time 1,313 hours/3,930 landings
Configuration Offshore
Engine PW210A x2
Flight rule SP IFR
Avionics phase 8

•2 additional sister-ships available
•Airframe and avionics covered by OEM programs
•Fresh 4 years inspection
•Emergency floats
•Single rescue hoist provisions
•Cargo hook provisions
•Utility active vibration absorber
•Maritime protection
•ADELT, TCAS II, HEELS
•Radio VHF/FM-H Maritime AEM NTX 138
•SATCOM Iridium Skytrac ISAT 200 A
•ADS-B out, HUMS, HTAWS, CVFDR with ULB
•Four axis AFCS with auto-hover

•ADELT with GPS NAV interface and GPS integrated
•TCAS II Rockwell Collins TSS-4100
•Weather Radar RDR 1600 MultiScan
•SATCOM Iridium Skytrac ISAT 200A
•Radio VHF/FM-H Maritime AEM NTX 138
•ADS-B out
•HUMS
•Flight data monitoring
•HTAWS
•Synthetic vision system
•Radar altimeter x2
•CVFDR with ULB
•Rockwell Collins display units 10" x 8" color AMLCD with
LED backlight and NVIS compatibility: two PFD and one
MFD
•Integrated standby instrument system
•Display control panels x2
•Cursor control devices x2
•Reversionary control panel
•Display dimming panel
•Master caution lights x2
•Master warning lights x2
•Avionics full duplex ethernet switches x2
•Aircraft monitoring and management system
•Aircraft monitoring & management computers x2
•One data transfer device
•Enhanced display and control units with touchscreen x2
•Four axis AFCS with auto-hover
•Dual flight control computer
•Flight control system control panel
•VHF-AM radios x2
•NAV VOR/ILS/MB receivers x2
•ADF
•DME
•Transponder with enhanced surveillance mode S
•SBAS GNSS GPS x2
•Interphone communication system
•Audio control panels x2
•Audio management unit interfacing external transceivers
•Passenger intercom amplifier
•Flux valves x2
•ADAHRS x2
•Digital clock integrated in display x2
•One standby magnetic compass...

•Kit emergency battery for ADI stdby with ventilation
•Kit upper deck accessibility RH instl
•Kit beanie main rotor
•Kit door lock passenger doors
•Cockpit door pockets
•Kit hinged fuel cap
•Kit interseat console extension
•Crew headset holder
•Crew door handles
•Kit camera in cockpit and cabin on DVAR
•Kit porthole AFT
•Single rescue hoist provisions
•Cargo hook provisions
•Cargo hook camera provisions
•Underbelly high intensity strobe lights
•Pop-up ventilation cabin window
•Main and tail rotor high visibility painting
•Emergency floats
•HEELS
•External life rafts on sponson
•Strobe lights
•Maritime protection
•OEI fuel transfer system
•Camera on the tail fin
•Co-pilot hinged window (storm window)
•Approach plates charts holders with lights for pilot and copilot
•with USB power outlet included
•Utility soft liners
•Utility active vibration absorber
•ICS configuration ‘’128’’
•Steps for cockpit / cabin access
•Rotor brake system
•Overhead cockpit windows sun shades
•First aid kit as per EU OPS 3 compliant
•One cockpit and one cabin fire extinguisher as per JAR OPS 3
•Cockpit compartment utility finishing interior
•Two cockpit panel sun-glare shields
•Crew crashworthy adjustable seats with inertial reels and
separate 5 points safety belts
•28V DC 10A cockpit/cabin power outlet
•Baggage compartment utility finishing interior including
door rain gutter
•Baggage smoke sensor
•USB socket interseat console
•Kit avionic bay ventilation
•One anti-collision light
•Navigation lights (red, white, green)
•Retractable swiveling landing/taxiing lights x2
•External emergency lights x2
•External lights night vision goggles friendly
